Specifications:

▪ Bending load cell

▪ Anodized aluminum construction, silicone sealed

▪ 3000 divisions OIML R60 class C

▪ IP65 protection

▪ High accuracy with decentralized loads

▪ Nominal loads (LN) 60-100-200 kg

▪ Accuracy class C3

▪ Output sensitivity 2.0 ± 0.1mV/V

▪ Minimum deadlift 0

▪ Safe overload 150% Emax

▪ Recommended excitation 10 V

▪ Maximum excitation 12 V

▪ Zero balance ≤±2% RO

▪ Input resistance 406±6 Ω

▪ Output resistance 350±3 Ω

▪ Insulation impedance ≥5000 MΩ

▪ Compensated temperature range -10 - +40 ºC

▪ Operating temperature range -30 - +80 ºC

▪ Maximum recommended platform size 400x400 mm

▪ Cable length 2m
