Specifications:

▪ Compression load cell with self-centering pivoting column

in stainless steel

▪ 3000 divisions OIML R60 class C and lightning protection

▪ Zone 0-1-2 (gas) and 20-21-22 (dust)

▪ Hermetically welded, IP69K protection (ISO 20653)

▪ Optimized corner preset for multi-cell systems

▪ Minimum load 0%LN

▪ Operating load 120%LN

▪ Load limit 150%LN

▪ Combined error <±0.017%Sn (1)

▪ Repeatability error <±0.015%Sn

▪ Temperature effect <±0.01%Sn/5ºk

▪ Sensitivity at zero <±0.006%Sn/5ºk

▪ Creep error (30 minutes) <±0.016%Sn

▪ Temperature compensation -10 - +40 ºC

▪ Temperature limits -30 - +70 ºC

▪ Nominal sensitivity (Sn) 2 mV/V (2)

▪ Nominal supply voltage 10 V

▪ Maximum supply voltage 15 V

▪ Input resistance 800±5 Ω

▪ Output resistance 700±5 Ω

▪ Initial imbalance < ±2%Sn

▪ Insulation resistance > 5000 MΩ

▪ Maximum deformation 0.6-1 mm

▪ Cable length 18 m
